Operation and control of heat exchanger

2008 – 2009

Supervised by:
Prof. Medhat Sorour



By:

Ahmed Saeed Abd-Elrazak

-Ahmed Mohamed Alaa

-Ahmed Naguib El-Shalakany

-Amr Mohamed Soliman

-Amr Mohamed El-Badry

-Philip Hassab Alla Nasr



Abstract:

Operation and control of Heat exchanger:

Design of double tube for heat exchanger and instruct it with flow controller and temperature controller to adjust the flow of cooling stream with different flow rate of the process flow and steps of operation:

1- Study of different type of heat exchangers.

2- Design of double tube heat exchanger.

3- Implementation of heat exchanger and installation of temperature and flow rate measuring device.

4- Performance test.

5- Technical report.



الملخص

التحكم فى المبادل الحرارى

نقوم فى المشروع بتصميم مبادل حرارى ثنائى الأنابيب مع تركيب أجهزة قياس كجهاز قياس معامل التدفق وجهاز قياس درجة الحراره وذلك لضبط التدفق للتيار البارد بنسب مختلفه لمعدل تدفق المائع.

خطوات العمل:

1- التعرف على المعادلات الحراريه.

2- تصميم مبادل حرارى ثنائى الأنابيب لتبادل كم محدد من الطاقه الحرارية.

3- تنفيذ المبادل الحرارى وتثبيت أجهزه قياس درجة الحرارة ومعدل التدفق.

4- الأختبارات والقياس.

5- التقرير الفنى.
