Improved design of a duct geometry for wave energy extraction system

2018 – 2019


Supervised by:

أ.د. محمد عباس قطب

د. أحمد سمير

د. رولا عفيفى



عمرو على رأفت

عمرو ادهم محمود سويلم

احمد محمود نعمان

محمد عبد الحميد احمد

احمد عبد الحميد نمر


Wells turbines can represent important source of renewable energy for many countries. An essential disadvantage of Wells turbines is their low aerodynamic efficiency and consequently low power produced. In order to enhance the Wells turbine performance, the present research work proposes the use of a symmetrical duct in the form of a venturi tube with turbine rotor located at throat. The effects of duct area ratio and duct angle are investigated in order to optimize Wells turbine performance.

A substantial improve of the turbine performance is achieved by optimizing the duct geometry. Increasing both the duct area ratio and duct angle increase the acceleration and deceleration upstream and downstream the rotor respectively. The accelerating flow with thinner boundary layer thickness upstream the rotor reduces the flow separation on the rotor suction side. The downstream diffuser reduces the interaction between tip leakage flow and blade suction side. Up to 14% increase in turbine power and 9% increase in turbine efficiency are achieved by optimizing the duct geometry. On other hand, a tangible delay of the turbine stall point is also detected.


Chapter (1) Introduction     Word           Pdf             Presentation

Final book           Presentation
